RGL Green Dome Exit Button | IP66 Rated | Surface or Flush Mount

Model Codes: EBGBWC02/PTE · EBGBWC02/DR · DL03Durable, Secure, and Easy to Use – Ideal for Internal or External Access Control Applications Overview The RGL Green Dome Exit Button is a high-durability, momentary-action button designed for access control systems in both general and sensitive areas. With a robust IP66-rated construction and wear-resistant legend, it ensures dependable performance in harsh environments and frequent-use settings. Key Features ✅ IP66 Rated Green Dome Button for internal or external use ✅ Momentary Contact Operation – Ideal for access control release ✅ High Impact Plastic Back Box – Surface or flush mount ✅ Double Pole Contact – N/O N/C (Normally Open/Normally Closed) ✅ Wear-Resistant Legends with anti-rotation mounting ✅ Security Screws (Allen Key Type) for tamper-resistance ✅ Easy-Clean, Large Button Surface for accessible operation Technical Specifications Parameter Specification Contact Type Double Pole N/O N/C Output Rating 4A @ 30V AC/DC Ingress Protection IP66 (Weatherproof) Material All-Plastic Button High-Impact Box Contact Resistance Max. 10m OHM Operating Travel 2mm Operating Temp. -20°C to 60°C Mounting Options Surface or flush with anti-rotation Dimensions 85mm x 85mm x 32mm Applications Public access points Clean environments (e.g., healthcare) Industrial or weather-exposed exits General exit or door release stations
